TBR25 Flanged Support Rail

The difference between TBR and SBR rails comes down to slider design. SBR uses a square slider on a hollow aluminum base to keep weight down; TBR uses a flanged slider with a solid base instead, which is the main reason it carries more load and holds up better under sustained pressure. The through-threaded holes in the TBR slider are the other practical difference - they let it mount either top-down or bottom-up, where an SBR slider only mounts top-down. That flexibility matters more than it sounds like when equipment layout is tight and the mounting orientation isn't a given.



TBR25 sits in the mid-to-larger end of the TBR size range, built for equipment loads that need the rigidity of a solid base rather than the reduced weight of a hollow one. We stock both SBR and TBR rail types, so if you're not sure which fits your load and mounting constraints, that's a straightforward question to work through with us before ordering.



We build to customer drawings or samples under OEM/ODM, with full size options available. Lead time is roughly 2–3 days for in-stock items, 8–15 days for made-to-order, depending on quantity and model. Packaged in neutral boxes or wooden crates depending on order size.



Below is the specification table for TBR guide rails, which includes specific parameters and available models. Should your desired model not be listed, please contact us.















1.Q: When can I get the quotation?

A: We usually quote within 24 hours after we get your inquiry. If you are very urgent to get the price,please call us or tell us in your email so that we will regard your inquiry priority.



2.Q:How long is your delivery time?

A:Generally, if the product is in stock, it will take 2-3 working days, and if it is not in stock, it will take 8-15 working days. It depends on the quantity, model, and whether it is customized.



3.Q: How can I get a sample to check your quality?

A: We are honoured to offer samples,You are requested to pay the shipping cost and some samples cost.



4.Q: Have items 100% finished in stock?

A: Most items are all well finished in stock, but some items are newly machined according to your requirements.



5.Q:Can I choose the sizes?

A: Yes, We have full size available for your to choose.



6.Q:What are your packaging conditions?

A: Generally speaking, our goods are packaged in neutral boxes and wooden boxes.
