TBR 20 Linear Motion Block Bearing

The TBR16 Cylinder Linear Guide Rail is designed for precise linear motion in CNC machines and transportation applications, offering reliable performance under heavy loads. Made from durable bearing steel and supported by an aluminum alloy structure, it ensures long-term stability and easy maintenance. With customizable lengths to meet specific requirements, this product suits machinery repair shops and manufacturing plants.





The TBR guide rail constitutes a cylindrical linear motion guide system comprising a T-shaped support bracket and a TBR slider. The rail body consists of a quenched and ground cylindrical steel rod mounted on the base for secure fixing and support. The slider incorporates a recirculating ball bearing assembly that rolls along the steel rod, delivering low friction and high precision characteristics.Models include TBR16, TBR20, TBR25, etc., where the number denotes the diameter of the guide rail.



Principal applications: Linear optical axes are extensively employed in automated transmission systems, including CNC machine tools, woodworking machinery, printing presses, industrial equipment, and similar apparatus.



Advantages of TBR Guide Rails:

Easy installation: Equipped with a base plate for direct bolting onto work surfaces

High precision, low friction: Incorporates a ball recirculation mechanism to minimise friction and enhance accuracy

Strong load-bearing capacity: Features highly rigid support rails with excellent bending resistance

Convenient maintenance: Sliders can be readily removed and replaced, facilitating routine maintenance of the guide system.













1.Q:How long does customization take?

A: Customization of linear guideways requires determining the size and specifications based on the requirements, which typically takes around 1-2 weeks for production and delivery after placing the order.



2.Q: What is your advantages?

A:1. Manufacturer,the most competitive price and good quality.

2. Perfect technical engineers give you the best support.

3. OEM is available.

4. Rich stock and quick delivery.



3.Q: How long has your company been in this field?

A: We have been focusing on automation machinery parts for ten years, and our products are sold all over the world, such as Europe, America, Asia, Southeast Asia, Africa and other places



4.Q: How long is your delivery time and shipment?

A:1.Sample Lead-times: generally 7 workdays.

2.Production Lead-times: 15-20 workdays after getting your deposit.



5.Q: If you can't find the product on our website,what do you next?

A:Please send us inquiry with product pictures and drawings by email or other ways and we'll check.
