Custom Machined Guide Shaft





Product Details
Made from bearing steel, GCr15 bearing steel, or a bearing-steel-on-aluminum-base construction, depending on the weight-to-stiffness ratio your application needs. Beyond standard turning and grinding, we handle threading, coaxial hole drilling and tapping, radial hole drilling and tapping, and reduced-diameter step sections - the kind of custom machining that turns a generic rod into a drop-in replacement for your existing shaft.



Product Description
Diameters run from 3mm through 150mm across twenty standard sizes, machined by CNC turning, milling, grinding, wire cutting, and EDM as the tolerance requires. Surface finish options include anodizing, polishing, zinc/nickel/chrome/gold plating, sandblasting, and phosphate coating, with color choices spanning silver, black, blue, red, gold, and olive for applications where the shaft is visible or needs to match equipment branding. These shafts show up in 3D printers, stepper-motor assemblies, printing and paper-processing machinery, textile equipment, material-handling and transport machinery, and - at the demanding end - aircraft flap actuators and nuclear reactor actuator systems.



We build to customer drawings or samples under OEM/ODM. Lead time is 3–7 days for samples and 15–20 days for bulk orders, depending on quantity and shop schedule.





Product Information
Product Name	Linear Guide Shaft
Material	Bearing steel guide, bearing steel aluminum base, GCr15 Bearing steel
Length	can be customized according to customers requirement
Model No.	Diameter (mm): 3, 4, 5, 6, 8, 10, 12, 13, 16, 20, 25, 30, 35, 40, 50, 60, 80, 100, 120, 150
Precision Processing	Drilling, Milling, CNC Turning, Grinding, Wire Cutting, EDM & etc.
Surface Finish	Anodize, Polishing, Zinc/ Nickel/ Chrome/ Gold Plating, Sand Blasting, Phosphate Coating & etc.
Part Color	Silver, Red, Blue, Gold, Oliver, Black, White & etc.
Our Services	Special requirement on machining, such as threading, coaxial holes drilled and tapped, radial holes drilled and tapped, reduced shaft diameter etc. We could supply OEM/ODM service to our customers.
Product Package	a. Plastic bag with box case or wooden case. b. According to our customer's request. We can provide shipping information to our customer at any time.
Delivery Time	3~7 days for sample order, 15~20 days for bulk order. Depends on the actual shipping situation.



Favorable Comment

Many customers arrived at the factory, they inspected the products in the factory, they are satisfied with the factory, the quality of the products and our services. Mutual Benefit and Collective Wins is the common goal we want to achieve with our customers.



FAQ

1. Q: What is the transportation?

A: If small quantity, we Suggest to send by express, such as DHL, UPS, TNT FEDEX. If large amount, by sea or air shipping.



2. Q: May I know what's the nearest airport from your company? In case I visit your company.

First Wenzhou Airport, then Hangzhou or Yiwu airport, welcome to visit us.



3. Q: Do you accept custom design on size?

A: Yes, if the size is reasonable.



4. Q: What are your terms of payment?

A: T/T or L/C



5. Q: What's your warranty terms?

A: We offer different warranty time for different products. Please contact with us for detailed warranty terms.
