HGH Guide Rail Series Linear Guide

Guide rails are mechanical guidance devices, typically constructed from metal or other materials. They primarily serve to guide and support moving components in reciprocating motion along a predetermined path (usually linear), while simultaneously bearing loads and minimising friction. Widely employed in industrial automation, precision machine tools, lifts, and automated equipment, they constitute a fundamental component within mechanical transmission systems.



Core Components

Guide Rail (Fixed Component): Typically a long, rectangular metal section with precision-machined surfaces providing a smooth guiding plane

Slider/Slide Block (Moving Component): Mounted on the moving part, containing rolling elements (balls, rollers, etc.) or sliding materials to traverse the guide rail

Rolling Elements: Balls, rollers, or needles facilitating rolling friction

Sealing Assembly: Prevents ingress of dust and contaminants, extending service life



Applications:

CNC Machine,Sewing Machine,ATC,Digitizer,Rooter,Lather Machine,Video Camera, Elevator,Transmission,Automation,Medical Equipment etc.

















1.Q: How long has your company been in this field?

A: We have been focusing on automation machinery parts for ten years, and our products are sold all over the world, such as Europe, America, Asia, Southeast Asia, Africa and other places



2.Q: What are your main products?

A: Our main products are linear shafts, linear bearings, ball screws, TBR linear guides, SBR linear guides, linear slide blocks and rod end bearings.



3.Q: What are your after-sales standards?

A: After our product is shipped, if there are any problems,please contact our sales personnel as soon as possible and we will handle them for you as soon as possible.



4. Q: Are you trading company or manufacturer ?
A: We are an manufacturer specializing.



5.Q: How long is your delivery time?
A: We have large stock, 5 days for stock items,7-20days for customize.
