HGW20 Flange Linear Guide Block

Product Details

Series: HGW

Nominal size: 20

Product type: Flange linear guide block

Compatible rail: HGR20

Rolling system: Recirculating steel balls

Load capability: Radial reverse radial and lateral directions

Applications: CNC machines automation equipment linear stages and positioning systems



Product Description

The HGW20 is a flange type linear guide block designed to run on a matching HGR20 profile rail. Recirculating balls travel through the block as it moves, providing low-friction linear guidance and supporting loads from multiple directions.



Its flange body provides a wider mounting surface than a square HGH block and allows the moving component to be fastened through the flange mounting holes. Proper rail alignment, mounting surface preparation, lubrication, and contamination protection are required for stable operation.



HGW20 is not a complete ordering code. The full suffix, such as HGW20CC or HGW20HC, must be confirmed because it identifies the block length and load configuration. The guide rail should not be assumed to be included unless the order specifically states that a rail and block set is supplied.



We accept orders as small as a single piece for standard sizes. Please contact us for delivery lead time based on order quantity.















1.Q:Can you provide free samples?

A:Yes, some normal products we can provide the free samples, but usually our customers need to bear the express charge

ustomized products sample need to pay the sample charge, when you placed the order, sample charge will be returned.



2.Q: How can I obtain the catalog?

A:Yes. Please contact us to get catalog.



3.Q:Customized Logo?

A:Yes, you can add your logo on bearings and packing box.

We supply OEM SERVICE including bearing's size, logo, packing, etc.



4.Q:How to contact us?

A:You can chat with us online, call us, send us email, send messages via trade manager, wechat, whatsapp, etc.



5.Q:Is there any after-sale service?

A:Customer services will watch for your order once your order placed to our company, we will keep in touch and ensure the quality is no problem until the goods arrived at your end.

Once you get the goods, please check the goods, if find out any problems to our goods, notify us, we will immediately get out the solutions for these.
