HGH15CA High Assembly Guide Block

Product Details

The HGH15CA is a square-type carriage from the HG series. It runs on a compatible HGR15 rail and uses recirculating steel balls between the block and the profiled raceways to support guided linear movement.



This page is for the HGH15CA block rather than the entire HGH model range. Rail length, accuracy class, preload and lubrication arrangement should be selected according to the complete guide assembly.



Product Description

Internal ball circuits allow the HGH15CA carriage to travel repeatedly along its matched rail with rolling contact. The high-assembly square body is intended for top mounting and provides a compact connection point for machine tables, fixtures and moving components.



Typical uses include CNC equipment, automation systems, measuring machinery and packaging equipment. Installation surfaces must be clean, flat and correctly aligned. Mixing rails and blocks from different series or tolerance groups may affect fit and running accuracy.



We build to customer drawings under OEM/ODM, and accept orders as small as a single piece for standard sizes.



Product Information

Item	Specification
Product Name	HGH15CA Linear Guide Block
Series	HG
Model	HGH15CA
Block Style	Square high assembly
Nominal Rail Size	15 mm
Compatible Rail	HGR15 profile rail
Rolling Element	Recirculating steel balls
Main Material	Bearing steel
Mounting	Threaded holes on top of block
Supply Form	Block only or matched rail and block assembly







1.Q:How is the service?

A:We provide good pre-sales, in-sales and after-sales services for you.



2.Q: How can I get pricing?

A: Email us (Samples or drawings provided be preferred), quantity you need, if any specific material or surface treatment required. We will send you quote within 48 hours.



3.Q:What is about the packing of the goods?

A:We use standard and strong export packing or according to your requirements.



4. Q:What is MOQ?

A:For inventory items, no minimum order quantity

For other items, would you please check our specific details for each item to get the MOQ. Any special requirement, please tell us.



5.Q:How to contact us?

A:You can chat with us online, call us, send us email, send messages via trade manager, wechat, whatsapp, etc.
